INDOOR LIGHTING · WALL LUMINAIRES
LFWLS-6W-3/4/6K-IP65-BK
Up-Down Wall Light 125 × 221 up-down
An up-down wall light in a 125 × 221 mm die-cast body, combining two 3 W emitters (SMD/COB) for 480 lm total. Offered at 3000K, 4000K or 6000K in black, with a 38° beam spread and a choice of internal or external driver.
6 W
WATTAGE
480 lm
OUTPUT
3000 / 4000 / 6000 K
COLOUR TEMP.
IP65
RATING
FINISH
Black
Mounting
HOW IT INSTALLSSURFACE
Fixed onto the surface — plane not specified by the manufacturer.
Technical Specifications
FROM CMS RECORD · LFWLS-6W-3/4/6K-IP65-BKLUMINAIRE DETAILS
Product CodeLFWLS-6W-3/4/6K-IP65-BK
Product TypeWall Light
Application AreaIndoor
PRODUCT DETAILS
Wattage6 W
Colour Temp.3000 / 4000 / 6000 K
IP RatingIP65
Chip TypeSMD/COB
Luminous Flux480 lm
CRI> 80
Beam Angle38°
Life Time50,000 Hours
DriverInternal / External
DimmingNon-Dimmable (On/Off)
Input Voltage230V AC
PHYSICAL DETAILS
Housing MaterialAlu Die Cast
Diffuser MaterialGlass
SizeW 125 × H 221 mm
Operating Temp.-20°C to +40°C
Storage Temp.-20°C to +50°C
Photometrics
480 lm
LUMEN OUTPUT
38 °
BEAM ANGLE
—
CENTRE BEAM
—
EFFICACY
3000 K
COLOUR TEMP.
80
CRI
