INDOOR LIGHTING · LED DOWNLIGHTS
LFDLR-40W-3K-IP44-WH/BK/SG
Twin Down Light twin recessed
A twin-lamp recessed downlight combining two 20 W COB modules (40 W total, per the factory code's 2X20W notation) behind a glass diffuser, set into a 195 mm ceiling cutout at 3000K. Rated IP44, offered in white, black or silver-grey.
40 W
WATTAGE
4400 lm
OUTPUT
3000 K
COLOUR TEMP.
IP44
RATING
FINISH
White
Black
Silver Gray
Mounting
HOW IT INSTALLSRECESSED
Set into the surface — plane not specified by the manufacturer.
Technical Specifications
FROM CMS RECORD · LFDLR-40W-3K-IP44-WH/BK/SGLUMINAIRE DETAILS
Product CodeLFDLR-40W-3K-IP44-WH/BK/SG
Product TypeDown Light
Application AreaIndoor
PRODUCT DETAILS
Wattage40 W
Colour Temp.3000 K
IP RatingIP44
Chip TypeCOB
Luminous Flux4400 lm
CRI> 80
Beam Angle24° / 36°
Life Time50,000 Hours
DriverExternal
DimmingNon-Dimmable (On/Off)
Input Voltage230V AC
PHYSICAL DETAILS
Housing MaterialAlu Die Cast
Diffuser MaterialGlass
SizeL 208 × W 105 × H 77 mm
Cutout195 mm
Operating Temp.-20°C to +40°C
Storage Temp.-20°C to +50°C
Photometrics
4400 lm
LUMEN OUTPUT
24 °
BEAM ANGLE
—
CENTRE BEAM
—
EFFICACY
3000 K
COLOUR TEMP.
80
CRI
