ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 00 · 2026 · 27/07
INDOOR LIGHTING · LED DOWNLIGHTS
Twin Down Light
twin recessed
LFDLR-40W-3K-IP44-WH/BK/SG
A twin-lamp recessed downlight combining two 20 W COB modules (40 W total, per the factory code's 2X20W notation) behind a glass diffuser, set into a 195 mm ceiling cutout at 3000K. Rated IP44, offered in white, black or silver-grey.
MOUNTING
Recessed
LUMINAIRE DETAILS
Product Code
LFDLR-40W-3K-IP44-WH/BK/SG
Product Type
Down Light
Application Area
Indoor
PRODUCT DETAILS
Wattage
40 W
Colour Temp.
3000 K
IP Rating
IP44
Chip Type
COB
Luminous Flux
4400 lm
CRI
> 80
Beam Angle
24° / 36°
Life Time
50,000 Hours
Driver
External
Dimming
Non-Dimmable (On/Off)
Input Voltage
230V AC
PHYSICAL DETAILS
Housing Material
Alu Die Cast
Diffuser Material
Glass
Size
L 208 × W 105 × H 77 mm
Cutout
195 mm
Operating Temp.
-20°C to +40°C
Storage Temp.
-20°C to +50°C
DIMENSIONAL DRAWING · MM
IMAGE TO BE SUPPLIED
PHOTOMETRIC · POLAR
LIGHT DISTRIBUTION
24°36°
FINISHES
White
Black
Silver Gray
LED
BridgeluxEpistarOsram
DRIVER
LifudEagleriseLuxflare
SUMMARY
WATTAGE
40
CCT
3000
INGRESS
44
FINISH
WH · BK · SG
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
LUXFLARE LIGHTINGREV 00 · 2026 · 27/07INDOOR
