OUTDOOR LIGHTING · WALL LUMINAIRES
LFWLR-10W-3K-IP65-BK
Step Light 10W step
A recessed step light in a 250 × 95 mm die-cast body with a 240 mm cutout, running a 10 W SMD module for 1200 lm behind a glass diffuser. Rated IP65 in black, with an internal driver and a 15° beam spread.
10 W
WATTAGE
1200 lm
OUTPUT
3000 K
COLOUR TEMP.
IP65
RATING
FINISH
Black
Mounting
HOW IT INSTALLSRECESSED
Set into the surface — plane not specified by the manufacturer.
Technical Specifications
FROM CMS RECORD · LFWLR-10W-3K-IP65-BKLUMINAIRE DETAILS
Product CodeLFWLR-10W-3K-IP65-BK
Product TypeWall Light
Application AreaOutdoor
PRODUCT DETAILS
Wattage10 W
Colour Temp.3000 K
IP RatingIP65
Chip TypeSMD
Luminous Flux1200 lm
CRI> 80
Beam Angle15°
Life Time50,000 Hours
DriverInternal
DimmingNon-Dimmable (On/Off)
Input Voltage230V AC
PHYSICAL DETAILS
Housing MaterialAlu Die Cast
Diffuser MaterialGlass
SizeL 250 × W 95 mm
Cutout240 mm
Operating Temp.-20°C to +55°C
Storage Temp.-20°C to +80°C
Photometrics
1200 lm
LUMEN OUTPUT
15 °
BEAM ANGLE
—
CENTRE BEAM
—
EFFICACY
3000 K
COLOUR TEMP.
80
CRI
