INDOOR LIGHTING · SPOT LIGHTS
LFSLR-1W-3K-IP20-WH/BK
Spot Light 1W Ø130 recessed
A 1 W recessed spot on a Ø130 mm body with a 120 mm cutout, delivering 100 lm through a 36° beam behind clear glass. Rated IP20 for dry-interior ceilings, in white or black.
1 W
WATTAGE
100 lm
OUTPUT
3000 K
COLOUR TEMP.
IP20
RATING
FINISH
White
Black
Mounting
HOW IT INSTALLSRECESSED
Set into the surface — plane not specified by the manufacturer.
Technical Specifications
FROM CMS RECORD · LFSLR-1W-3K-IP20-WH/BKLUMINAIRE DETAILS
Product CodeLFSLR-1W-3K-IP20-WH/BK
Product TypeSpot Light
Application AreaIndoor
PRODUCT DETAILS
Wattage1 W
Colour Temp.3000 K
IP RatingIP20
Chip TypeCob
Luminous Flux100 lm
CRI> 80
Beam Angle36°
Life Time50,000 Hours
DriverExternal
DimmingNon-Dimmable (On/Off)
Input Voltage230V AC
PHYSICAL DETAILS
Housing MaterialAlu Die Cast
Diffuser MaterialGlass
SizeØ 130 × H 160 mm
Cutout120 mm
Operating Temp.-20°C to +40°C
Storage Temp.-20°C to +50°C
Photometrics
100 lm
LUMEN OUTPUT
36 °
BEAM ANGLE
—
CENTRE BEAM
—
EFFICACY
3000 K
COLOUR TEMP.
80
CRI
