ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 02 · 2026 · 17/08
INDOOR LIGHTING · SPOT LIGHTS
Spot Light 1W Ø130
recessed
LFSLR-1W-3K-IP20-WH/BK
A 1 W recessed spot on a Ø130 mm body with a 120 mm cutout, delivering 100 lm through a 36° beam behind clear glass. Rated IP20 for dry-interior ceilings, in white or black.
MOUNTING
Recessed
LUMINAIRE DETAILS
Product Code
LFSLR-1W-3K-IP20-WH/BK
Product Type
Spot Light
Application Area
Indoor
PRODUCT DETAILS
Wattage
1 W
Colour Temp.
3000 K
IP Rating
IP20
Chip Type
Cob
Luminous Flux
100 lm
CRI
> 80
Beam Angle
36°
Life Time
50,000 Hours
Driver
External
Dimming
Non-Dimmable (On/Off)
Input Voltage
230V AC
PHYSICAL DETAILS
Housing Material
Alu Die Cast
Diffuser Material
Glass
Size
Ø 130 × H 160 mm
Cutout
120 mm
Operating Temp.
-20°C to +40°C
Storage Temp.
-20°C to +50°C
DIMENSIONAL DRAWING · MM
IMAGE TO BE SUPPLIED
PHOTOMETRIC · POLAR
LIGHT DISTRIBUTION
36°
FINISHES
White
Black
LED
BridgeluxEpistarOsram
DRIVER
LifudEagleriseLuxflareNZ
SUMMARY
WATTAGE
1
CCT
3000
INGRESS
20
FINISH
WH · BK
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
