ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 03 · 2026 · 27/07
OUTDOOR LIGHTING · LED DOWNLIGHTS
Wall Mounted Downward Light
wall surface
LFDTWS-10W-3K-IP65-BL
Wall-mounted downward luminaire for exterior walls — die-cast aluminium with a clear-glass diffuser, washing entrances and façades with a directed 90° beam.
MOUNTING
Wall surface
LUMINAIRE DETAILS
Product Code
LFDTWS-10W-3K-IP65-BL
Product Type
Down Light
Application Area
Outdoor
PRODUCT DETAILS
Wattage
10 W
Colour Temp.
3000 K
IP Rating
IP65
Chip Type
SMD
Luminous Flux
750 lm
CRI
> 80
Beam Angle
90°
Life Time
50,000 Hours
Driver
Integrated
Dimming
Non-Dimmable (On/Off)
Input Voltage
230V AC
PHYSICAL DETAILS
Housing Material
Alu Die Cast
Diffuser Material
Glass
Diffuser Optics
Clear
Operating Temp.
-20°C to +55°C
Storage Temp.
-20°C to +80°C
DIMENSIONAL DRAWING · MM
PHOTOMETRIC · POLAR
LIGHT DISTRIBUTION
90°
FINISHES
Black
LED
BridgeluxEpistar
DRIVER
Luxflare
SUMMARY
WATTAGE
10
CCT
3000
INGRESS
65
FINISH
BL
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
