ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 01 · 2026 · 27/07
INDOOR LIGHTING · LED DOWNLIGHTS
Surface Down Light
linear surface
LFDLCS-20W-3K-IP44-BK
Surface-mounted five-cell linear downlight — die-cast aluminium with clear-glass optics in 50° or 70°, for corridors and rooms without recess depth.
MOUNTING
Surface
LUMINAIRE DETAILS
Product Code
LFDLCS-20W-3K-IP44-BK
Product Type
Down Light
Application Area
Indoor
PRODUCT DETAILS
Wattage
20 W
Colour Temp.
3000 K
IP Rating
IP44
Chip Type
SMD
Luminous Flux
1400 lm
CRI
> 80
Beam Angle
50° · 70°
Life Time
50,000 Hours
Driver
External/Integrated
Dimming
Non-Dimmable (On/Off)
Input Voltage
230V AC
PHYSICAL DETAILS
Housing Material
Alu Die Cast
Diffuser Material
Glass
Diffuser Optics
Clear
Size
L 195 x W 43 x H 66mm
Operating Temp.
-20°C to +40°C
Storage Temp.
-20°C to +50°C
DIMENSIONAL DRAWING · MM
PHOTOMETRIC · POLAR
LIGHT DISTRIBUTION
50°70°
FINISHES
Black
LED
BridgeluxEpistarOsram
DRIVER
LifudEagleriseLuxflare
SUMMARY
WATTAGE
20
CCT
3000
INGRESS
44
FINISH
BK
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
