ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 00 · 2026 · 27/07
OUTDOOR LIGHTING · IN-GROUND
RGBW Inground Linear Light
rgbw linear
LFIGFR-15W-__K-IP67-WH/SG
A 1000 mm RGBW colour-changing inground linear light, 15 W in an extruded aluminium body behind a polycarbonate diffuser at 180°, run from 24V DC. Rated IP67, in white or silver-grey. Colour-changing output has no single correlated colour temperature, so CCT is not specified.
MOUNTING
Floor recessed
LUMINAIRE DETAILS
Product Code
LFIGFR-15W-__K-IP67-WH/SG
Product Type
In-ground Light
Application Area
Outdoor
PRODUCT DETAILS
Wattage
15 W
Colour Temp.
—
IP Rating
IP67
Chip Type
COB
Luminous Flux
600 lm
CRI
> 80
Beam Angle
180°
Life Time
50,000 Hours
Driver
External
Dimming
Non-Dimmable (On/Off)
Input Voltage
24V DC
PHYSICAL DETAILS
Housing Material
Aluminium (Extruded)
Diffuser Material
Polycarbonate (PC)
Size
L 1000 × W 26 × H 25 mm
Operating Temp.
-20°C to +55°C
Storage Temp.
-20°C to +80°C
DIMENSIONAL DRAWING · MM
IMAGE TO BE SUPPLIED
PHOTOMETRIC · POLAR
LIGHT DISTRIBUTION
180°
FINISHES
White
Silver Gray
LED
BridgeluxEpistarOsram
DRIVER
LifudEagleriseLuxflare
SUMMARY
WATTAGE
15
CCT
—
INGRESS
67
FINISH
WH · SG
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
