ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 00 · 2026 · 29/07
OUTDOOR LIGHTING · SPOT LIGHTS
Outdoor Spot Light
sealed
LFSLS-12W-3K-IP65-WH/BK/SG
A 12 W surface-mounted outdoor spotlight in a Ø75 mm, 115 mm-tall body, producing 986 lm through a tight 15° beam behind clear glass. Rated IP65, in white, black or silver-grey on 230V AC.
MOUNTING
Surface
LUMINAIRE DETAILS
Product Code
LFSLS-12W-3K-IP65-WH/BK/SG
Product Type
Spot Light
Application Area
Outdoor
PRODUCT DETAILS
Wattage
12 W
Colour Temp.
3000 K
IP Rating
IP65
Chip Type
Cob
Luminous Flux
986 lm
CRI
> 80
Beam Angle
15°
Life Time
50,000 Hours
Driver
External
Dimming
Non-Dimmable (On/Off)
Input Voltage
230V AC
PHYSICAL DETAILS
Housing Material
Alu Die Cast
Diffuser Material
Glass
Size
Ø 75 × H 115 mm
Operating Temp.
-20°C to +55°C
Storage Temp.
-20°C to +80°C
DIMENSIONAL DRAWING · MM
IMAGE TO BE SUPPLIED
PHOTOMETRIC · POLAR
LIGHT DISTRIBUTION
15°
FINISHES
White
Black
Silver Gray
LED
CreeBridgelux
DRIVER
LifudLuxflareNZ
SUMMARY
WATTAGE
12
CCT
3000
INGRESS
65
FINISH
WH · BK · SG
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
