ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 00 · 2026 · 27/07
OUTDOOR LIGHTING · IN-GROUND
Inground Light 7W
floor recessed
LFIGFR-7W-3K-IP67-BK/SG
The 7 W sibling of the inground light range — the same steel housing, glass diffuser and 120° spread, non-dimmable. Rated IP67, in black or silver-grey.
MOUNTING
Floor recessed
LUMINAIRE DETAILS
Product Code
LFIGFR-7W-3K-IP67-BK/SG
Product Type
In-ground Light
Application Area
Outdoor
PRODUCT DETAILS
Wattage
7 W
Colour Temp.
3000 K
IP Rating
IP67
Chip Type
COB
Luminous Flux
560 lm
CRI
> 80
Beam Angle
120°
Life Time
50,000 Hours
Driver
External
Dimming
Non-Dimmable (On/Off)
Input Voltage
230V AC
PHYSICAL DETAILS
Housing Material
STEEL
Diffuser Material
Glass
Size
Ø 120 × H 105 mm
Operating Temp.
-20°C to +55°C
Storage Temp.
-20°C to +80°C
DIMENSIONAL DRAWING · MM
IMAGE TO BE SUPPLIED
PHOTOMETRIC · POLAR
LIGHT DISTRIBUTION
120°
FINISHES
Black
Silver Gray
LED
BridgeluxEpistarOsram
DRIVER
LifudLuxflareNZ
SUMMARY
WATTAGE
7
CCT
3000
INGRESS
67
FINISH
BK · SG
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
