ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 01 · 2026 · 17/08
OUTDOOR LIGHTING · WALL WASHERS
Flexible Wall Washer
flexible
LFFWS-15W-3K-IP67-WH
A compact wall washer in a 25 × 27 mm die-cast body, running an SMD module at 15 W for 1650 lm behind a glass diffuser. Rated IP67 with an external driver, in white, at a 30° beam angle.
MOUNTING
Surface
LUMINAIRE DETAILS
Product Code
LFFWS-15W-3K-IP67-WH
Product Type
Wall Washer
Application Area
Outdoor
PRODUCT DETAILS
Wattage
15 W
Colour Temp.
3000 K
IP Rating
IP67
Chip Type
SMD
Luminous Flux
1650 lm
CRI
> 80
Beam Angle
30°
Life Time
50,000 Hours
Driver
External
Dimming
Non-Dimmable (On/Off)
Input Voltage
24V DC
PHYSICAL DETAILS
Housing Material
Alu Die Cast
Diffuser Material
Glass
Size
W 27 × H 25 mm
Operating Temp.
-20°C to +55°C
Storage Temp.
-20°C to +80°C
DIMENSIONAL DRAWING · MM
IMAGE TO BE SUPPLIED
PHOTOMETRIC · POLAR
LIGHT DISTRIBUTION
30°
FINISHES
White
LED
LumiledsBridgeluxEpistarOsram
DRIVER
LifudEagleriseLuxflareNZ
SUMMARY
WATTAGE
15
CCT
3000
INGRESS
67
FINISH
WH
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
