ARCHITECTURAL LED LIGHTING
PRODUCT DATASHEET
REV 02 · 2026 · 31/08
OUTDOOR LIGHTING · BOLLARDS
Bollard Light
pathway
LF-BL-F-S-7W-3K IP65
Product overview to be supplied.
MOUNTING
—
LUMINAIRE DETAILS
Product Code
LF-BL-F-S-7W-3K IP65
Product Type
Bollard Light
Application Area
Outdoor
PRODUCT DETAILS
Wattage
7 / 10 W
Colour Temp.
3000 K
IP Rating
IP65
Chip Type
COB
Luminous Flux
770 / 1100 lm
CRI
> 70
Beam Angle
120°
Life Time
50,000 Hours
Driver
Integrated
Dimming
Non-Dimmable (On/Off)
Input Voltage
230V AC
PHYSICAL DETAILS
Housing Material
Alu Die Cast
Diffuser Material
Polycarbonate (PC)
Diffuser Optics
Clear
Size
W 120 × H 500 mm
Operating Temp.
-20°C to +55°C
Storage Temp.
-20°C to +80°C
Size (2)
H 900
DIMENSIONAL DRAWING · MM
FINISHES
RAL 7026
Custom Colour
LED
BridgeluxEpistar
DRIVER
Luxflare
SUMMARY
WATTAGE
7 · 10
CCT
3000
INGRESS
65
FINISH
CS
Technical data in accordance with EN 60598-1, EN 62031, EN IEC 63000 (RoHS), EU LVD 2014/35/EU and EN/IEC 60529 (IP code). We reserve the right to make technical and design changes.
